MAHR Micromar 46 EWR Digital Micrometer Head

MAHR Micromar 46 EWR Digital Micrometer Head
MAHR Micromar 46 EWR Digital Micrometer Head

MAHR Micromar 46 EWR Digital Micrometer Head

  • High contrast analog display
  • Rapid drive with integrated ratchet
  • Immediate measurements due to the Reference System
  • Digimatic
  • Opto RS-232C
  • USB
  • Battery life approx. 2 years
  • IP 52
  • end cap (in case the rapid drive is not required)
  • instruction manual
  • battery
  • case
8.5 mm
Ask a question
Description Iespējas Specifikācija Video

Micromar 46 EWR Digital Micrometer Head

Technical data



Order no.Measuring range mmMeasuring range inchResolution mm/inchError limit µmSpindle diameterSpindle thread pitch_mm
4184306
0 – 25
0 – 1″
0.001 / .00005″
4 µm
6.5 mm
0.635 mm
4184308
0 – 25
0 – 1″
0.001 / .00005″
4 µm
6.5 mm
0.635 mm



Functions

  • RESET (set display to zero)
  • ABS (display can be set to zero without losing reference to preset)
  • PRESET (for entering a numerical value)
  • LOCK function (key lock)
  • mm/inch
  • Reversal of counting direction
