Qness (QATM) ATM Inspect

for microscopic evaluation and documentation

Ask a question

Description

ATM Inspect

EVALUATION SOFTWARE

The software package QATM Inspect is characterized by intuitive and user-friendly design and provides an extensive toolbox for microscopic evaluation and documentation of results. The software basis comprises a wealth of features and is adaptable to customer-specific tasks. It is easily extendable with a variety of add-on modules.

With QATM Inspect microscoping tasks are executed rapidly, easily and with utmost precision. QATM Inspect extends the range of functions of stereo microscopes and/or reflected light microscopes with interactive in-image-measurements and the generation of customized reports. Measurement and report templates help to increase throughput rates for routine tasks.

The automatic brightness adjustment and the automatic shading correction lead to fast and usable image results. Simple measurements like lengths and areas may be inserted into the image by using overlay elements. Additionally, the software basis provides measurement instruments for the statistical evaluation of layer thicknesses and grain sizes. Additionally, the software is able to load, to recalibrate and to size external images.

The software has been developed to accommodate either touch or mouse operation in a 64-bit-Version (WIN 7/8/10). A modular software structure allows the user to extend the portfolio of functions any time. The microstructure analysis add-ons increase the degree of automation for phase analyses, layer thicknesses and grain sizes.

Product Advantages

Interactive in-image-measurements and report generator

Compatible with reflected light microscopes and/or stereo microscopes

Opportunity to integrate multiple microscope cameras

Result documentation via images and customized reports

Extensible with microstructure analysis add-ons

QATM INSPECT

Key Features

Interactive Measurements

Measure lengths, areas, angles and free forms

Alignment of objects using coordinates and angles

Customizable in color, font, size and style

Lock individual metrics

Measurement templates for recurrent samples

Report Generator

Output of value tables, images and diagrams

Insertion of form fields

Individual styling with drag and drop

Template management for recurrent test reports

Inspect Phase Analysis

Automatized image object measurement

Measurement of phase fractions according to ISO 9042 and ASTM E562-11

Output of analysis results in terms of the relative/absolute area in tables or graphs

Statistical quantities (e.g. mean, standard deviation, median, minimum, maximum)

Inspect Coating Thickness

Measurement of coating thickness according to DIN EN ISO 1463

Semi-automatic measurement of horizontally and vertically aligned coatings and curved coatings

Output of analysis results in terms of individual thicknesses in tables or graphs

Output of the coating thickness in terms of statistical quantities (e.g. mean,standard deviation, median,minimum, maximum)

Inspect Grain Size Analysis

Measurement of the grain size according to DIN EN ISO 643 and ASTM E112-13 including lineal and circular intercept procedures

Output of analysis results in terms of tables and graphs

Acquisition of statistical quantities of the grain size as well as of the grain intercept lengths (e.g. mean, standard deviation, median, minimum, maximum)
