MAHR Micromar 46 EWR Digital Micrometer Head

MAHR Micromar 46 EWR Digital Micrometer Head
MAHR Micromar 46 EWR Digital Micrometer Head

MAHR Micromar 46 EWR Digital Micrometer Head

  • High contrast analog display

  • Rapid drive with integrated ratchet

  • Immediate measurements due to the Reference System

  • Digimatic

  • Opto RS-232C

  • USB

  • Battery life approx. 2 years

  • IP 52

  • end cap (in case the rapid drive is not required)

  • instruction manual

  • battery

  • case

8.5 mm

Ask a question
Description

Micromar 46 EWR Digital Micrometer Head

Technical data

Order no.Measuring range mmMeasuring range inchResolution mm/inchError limit µmSpindle diameterSpindle thread pitch_mm
4184306

0 - 25

0 - 1"

0.001 / .00005"

4 µm

6.5 mm

0.635 mm
4184308

0 - 25

0 - 1"

0.001 / .00005"

4 µm

6.5 mm

0.635 mm



Functions

  • RESET (set display to zero)

  • ABS (display can be set to zero without losing reference to preset)

  • PRESET (for entering a numerical value)

  • LOCK function (key lock)

  • mm/inch

  • Reversal of counting direction
