Technical data
| Order no. | Measuring range mm | Graduation value mm | Error limit µm | Spindle thread pitch_mm | Error limit |
|---|---|---|---|---|---|
| 4168001 | 100 - 125 | 0,01 | 6 µm | 0.5 mm | 4+(l/100)µm l= length of the combination in mm |
| 4168020 | 100 - 150 | 0,01 | 0.5 mm | 4+(l/100)µm l= length of the combination in mm | |
| 4168021 | 100 - 300 | 0,01 | 0.5 mm | 4+(l/100)µm l= length of the combination in mm | |
| 4168022 | 100 - 500 | 0,01 | 0.5 mm | 4+(l/100)µm l= length of the combination in mm | |
| 4168023 | 100 - 900 | 0,01 | 0.5 mm | 4+(l/100)µm l= length of the combination in mm |
