| Order no. | Measuring range mm | Graduation value mm | Error limit µm | Notes error limit | Spindle thread pitch_mm |
|---|---|---|---|---|---|
| 4190310 | 6 - 8 | 0,001 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190311 | 8 - 10 | 0,001 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190312 | 10 - 12 | 0,001 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190313 | 12 - 16 | 0,001 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190314 | 16 - 20 | 0,001 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190315 | 20 - 25 | 0,005 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190316 | 25 - 30 | 0,005 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190317 | 30 - 40 | 0,005 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190319 | 40 - 50 | 0,005 | 4 µm | over the full length of the anvils | 0.5 mm |
| 4190320 | 50 - 60 | 0,005 | 5 µm | over the full length of the anvils | 0.5 mm |
| 4190321 | 60 - 70 | 0,005 | 5 µm | over the full length of the anvils | 0.5 mm |
| 4190012 | 70 - 85 | 0,005 | 5 µm | over the full length of the anvils | 0.5 mm |
| 4190013 | 85 - 100 | 0,005 | 5 µm | over the full length of the anvils | 0.5 mm |
| 4190014 | 100 - 125 | 0,005 | 6 µm | over the full length of the anvils | 0.5 mm |
| 4190015 | 125 - 150 | 0,005 | 6 µm | over the full length of the anvils | 0.5 mm |
| 4190016 | 150 - 175 | 0,005 | 7 µm | over the full length of the anvils | 0.5 mm |
| 4190017 | 175 - 200 | 0,005 | 7 µm | over the full length of the anvils | 0.5 mm |
