Technical data
| Order no. | Measuring range mm | Graduation value mm | Error limit µm | Parallel error in µm | Flatness in µm | Spindle diameter | Spindle thread pitch_mm |
|---|---|---|---|---|---|---|---|
| 4137500 | 0 - 100 | 0,01 | 5 µm | 3 µm | 0.6 µm | 8 mm | 1 mm |
| 4137501 | 100 - 200 | 0,01 | 7 µm | 4 µm | 0.6 µm | 8 mm | 1 mm |
| 4137502 | 200 - 300 | 0,01 | 9 µm | 5 µm | 0.6 µm | 8 mm | 1 mm |
| 4137503 | 300 - 400 | 0,01 | 11 µm | 6 µm | 0.6 µm | 8 mm | 1 mm |
| 4137504 | 400 - 500 | 0,01 | 13 µm | 7 µm | 0.6 µm | 8 mm | 1 mm |
| 4137505 | 500 - 600 | 0,01 | 21 µm | 8 µm | 0.6 µm | 8 mm | 1 mm |
| 4137506 | 600 - 700 | 0,01 | 23 µm | 8 µm | 0.6 µm | 8 mm | 1 mm |
| 4137507 | 700 - 800 | 0,01 | 26 µm | 9 µm | 0.6 µm | 8 mm | 1 mm |
| 4137508 | 800 - 900 | 0,01 | 28 µm | 11 µm | 0.6 µm | 8 mm | 1 mm |
| 4137509 | 900 - 1000 | 0,01 | 30 µm | 11 µm | 0.6 µm | 8 mm | 1 mm |
