Technical data
| Order no. | Measuring range mm | Error limit µm | Parallel error in µm | Flatness in µm | Spindle diameter | Spindle thread pitch_mm | Dial color | Type of dial face | Dial comparator measuring range | Graduation value µm | Measuring force (N) | Measuring force | Error limit Ge (µm) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 4154030 | 0 - 50 | 2 µm | 2 µm | 0.2 µm | 7.5 mm | 0.5 mm | Yellow | 50-0-50 | ± 50 | 1 µm | 6.5 | 6.5 N | 1 µm |
| 4154031 | 0 - 50 | 2 µm | 2 µm | 0.2 µm | 7.5 mm | 0.5 mm | ± | 6.5 | 6.5 N |
