| Order no. | Measuring range mm | Measuring range inch | Resolution mm/inch | Error limit µm | Parallel error in µm | Flatness in µm | Spindle diameter | Spindle thread pitch_mm | Measuring force (N) |
|---|---|---|---|---|---|---|---|---|---|
| 4157100 | 0 - 25 | 0 - 1" | 0.001 / .00005" | 2 µm | 2 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157101 | 25 - 50 | 1 - 2" | 0.001 / .00005" | 2 µm | 2 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157102 | 50 - 75 | 2 - 3" | 0.001 / .00005" | 3 µm | 3 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157103 | 75 - 100 | 3 - 4" | 0.001 / .00005" | 3 µm | 3 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157104 | 100 - 125 | 4 - 5" | 0.001 / .00005" | 6 µm | 3 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157105 | 125 - 150 | 5 - 6" | 0.001 / .00005" | 6 µm | 3 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157106 | 150 - 175 | 6 - 7" | 0.001 / .00005" | 7 µm | 4 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
| 4157107 | 175 - 200 | 7 - 8" | 0.001 / .00005" | 7 µm | 4 µm | 0.6 µm | 6.5 mm | 0.5 mm | 5 - 10 |
