Technical data
| Order no. | Measuring range mm | Graduation value mm | Error limit µm | Spindle diameter | Spindle thread pitch_mm |
|---|---|---|---|---|---|
| 4134000 | 0 - 25 | 0,01 | 4 µm | 6.5 mm | 0.5 mm |
| 4134001 | 25 - 50 | 0,01 | 4 µm | 6.5 mm | 0.5 mm |
| 4134002 | 50 - 75 | 0,01 | 5 µm | 6.5 mm | 0.5 mm |
| 4134003 | 75 - 100 | 0,01 | 5 µm | 6.5 mm | 0.5 mm |
| 4134004 | 100 - 125 | 0,01 | 6 µm | 6.5 mm | 0.5 mm |
| 4134005 | 125 - 150 | 0,01 | 6 µm | 6.5 mm | 0.5 mm |
| 4134006 | 150 - 175 | 0,01 | 7 µm | 6.5 mm | 0.5 mm |
| 4134007 | 175 - 200 | 0,01 | 7 µm | 6.5 mm | 0.5 mm |
