MAHR MarCal 16 ER Digital Caliper

MAHR MarCal 16 ER Digital Caliper
MAHR MarCal 16 ER Digital Caliper

MAHR MarCal 16 ER Digital Caliper

  • High contrast analog display

  • Locking screw above

  • Lapped guideway

  • Measuring blade for inside measurements

  • Slide and beam made of hardened stainless steel

  • Step measuring function

  • Immediate measurements due to the Reference System

  • Raised guideway for the protection of the scale

  • Dirt wipers are integrated in the slide

  • none

  • None

  • instruction manual

  • battery

  • case

  • Battery life approx. 3 years

Height of digits

  • 11 m

Ask a question
Description
Technical data

Order no.Measuring range mmMeasuring range inchResolution mm/inchError limit (mm)Error limit inchesStandardFriction wheelDepth Rod
4103010

0 - 150

0 - 6"

0.01 / .0005"

0.03 mm

.001"

DIN 862

no

round
4103011

0 - 150

0 - 6"

0.01 / .0005"

0.03 mm

.001"

DIN 862

yes

round
4103012

0 - 150

0 - 6"

0.01 / .0005"

0.03 mm

.001"

DIN 862

no

rectangular
4103013

0 - 150

0 - 6"

0.01 / .0005"

0.03 mm

.001"

DIN 862

yes

rectangular
4103205

0 - 200

0 - 8"

0.01 / .0005"

0.03 mm

.001"

DIN 862

no

rectangular
4103206

0 - 200

0 - 8"

0.01 / .0005"

0.03 mm

.001"

DIN 862

yes

rectangular
4103207

0 - 300

0 - 12"

0.01 / .0005"

0.04 mm

.0015"

Factory standard

no

4103208

0 - 300

0 - 12"

0.01 / .0005"

0.04 mm

.0015"

Factory standard

yes



Functions

  • ON/OFF

  • AUTO-ON / OFF

  • RESET (set display to zero)

  • mm/inch

  • LOCK function (key lock)
