MAHR MaraMeter 853 Indicating thread snap gage

MAHR MaraMeter 853 Indicating thread snap gage
MAHR MaraMeter 853 Indicating thread snap gage

MAHR MaraMeter 853 Indicating thread snap gage

  • Rugged, forged steel frame with heat insulators

  • Measuring spindle is mounted in long guideway with lever controlled retraction

  • Anvil spindle adjustable with thumbscrew via worm and rack, for mounting interchangeable support yokes

  • Measuring spindle and anvil are made of hardened stainless steel with mounting bore for insertion of interchangeable anvils

  • Anvil spindle can easily be fine adjusted

  • Constant measuring force as a result of built-in spring, eliminating user influence

  • Maximum wear resistance due to non-contact positioning

Ask a question
Description

MaraMeter 853 Indicating thread snap gage

Technical data

Order no.Product typeApplication range mmMeasuring span in mmRepeatability fw (µm)Measuring force
4511000

853

1.2 - 35

8 mm

2 µm

7.5 N
4511001

853

35 - 75

8 mm

2 µm

7.5 N
