MAHR MaraMeter 852 Indicating thread snap gage

MAHR MaraMeter 852 Indicating thread snap gage

  • Rugged, forged steel frame with heat insulators
  • Measuring spindle is mounted in long guideway with lever controlled retraction
  • Measuring spindle and anvil are made of hardened stainless steel with mounting bore for insertion of interchangeable anvils
  • Adjustable center stop for automatic alignment
  • Anvil spindle can easily be fine adjusted
  • Constant measuring force as a result of built-in spring, eliminating user influence
  • Maximum wear resistance due to non-contact positioning in conjunction with carbide tipped measuring faces

MaraMeter 852 Indicating thread snap gage

Technical data

Order no.Product typeApplication range mmMeasuring span in mmRepeatability fw (µm)Measuring force
4510000

852

0 - 45

2 mm

1 µm

7.5 N
4510001

852

45 - 85

2.5 mm

1 µm

7.5 N
4510002

852

85 - 140

2.5 mm

1 µm

9 N
4510003

852

140 - 190

2.5 mm

1 µm

9 N
