MAHR MaraMeter 844 z2 Measuring head

MAHR MaraMeter 844 z2 Measuring head
MAHR MaraMeter 844 z2 Measuring head

MAHR MaraMeter 844 z2 Measuring head

  • Maximum wear resistance due to carbide ball anvils

  • Constant measuring force due to built-in spring, eliminating user influence

  • Anvils, measuring heads, holder, spacer (intermediate piece) and depth extensions form a very comprehensive modular system which can rapidly be converted to measure further gear sizes

  • When ordering please state the required ball diameter

Ask a question
Description

MaraMeter 844 z2 Measuring head

Technical data

Order no.Product typeMeasuring range mmDimension over balls MdKRepeatability fw (µm)Error limit Ge (µm)
4485000

844 z1

23.5 - 26.5

26 - 130.5

1 µm

6 µm
4485001

844 z2

46 - 49

48.5 - 333

1 µm

6 µm
