| Order no. | Product type | Application range mm | Tooth spans | Measuring span in mm | Size of measuring surface in mm | Parallel error in µm | Flatness in µm | Repeatability fw (µm) | Measuring force |
|---|---|---|---|---|---|---|---|---|---|
| 4452000 | 840 FM | 0 - 40 | 0.5 | 2 mm | 12 x 12 mm | 2 µm | 0.5 µm | 1 µm | 7.5 N |
| 4452001 | 840 FM | 40 - 80 | 0.5 | 2.5 mm | 12 x 12 mm | 3 µm | 0.5 µm | 1 µm | 7.5 N |
| 4452002 | 840 FM | 80 - 130 | 1 | 2.5 mm | 15 x 17 mm | 3 µm | 0.5 µm | 1 µm | 9 N |
| 4452003 | 840 FM | 130 - 180 | 1 | 2.5 mm | 15 x 17 mm | 3 µm | 0.5 µm | 1 µm | 9 N |
