| Order no. | Product type | Measuring range inch | Measuring range mm | Distance of movable anvil_mm | Repeatability fw (µm) | Error limit Ge (µm) | Measuring depth mm |
|---|---|---|---|---|---|---|---|
| 4474000 | 844 N | .7 - 2" | 18 - 50 | 1.3 mm | 0.5 µm | 2 µm | 115 mm |
| 4474001 | 844 N | 1.4 - 4" | 35 - 100 | 1.3 mm | 0.5 µm | 2 µm | 148 mm |
| 4474002 | 844 N | 4 - 10" | 100 - 250 | 1.6 mm | 0.5 µm | 2 µm | 230 mm |
| 4474003 | 844 N | 10 - 16" | 250 - 400 | 2.6 mm | 1.5 µm | 3 µm | 366 mm |
| 4474004 | 844 N | 16 - 32" | 400 - 800 | 2.6 mm | 1.5 µm | 3 µm | 366 mm |
| 4474005 | 844 N | 10 - 32" | 250 - 800 | 2.6 mm | 1.5 µm | 3 µm | 366 mm |
| Order no. | Product type | Measuring range inch | Measuring range mm | Distance of movable anvil_mm | Repeatability fw (µm) | Error limit Ge (µm) | Measuring depth mm |
|---|---|---|---|---|---|---|---|
| 4475000 | 844 NH | .7 - 2" | 18 - 50 | 1.3 mm | 0.5 µm | 2 µm | 115 mm |
| 4475001 | 844 NH | 1.4 - 4" | 35 - 100 | 1.3 mm | 0.5 µm | 2 µm | 148 mm |
| 4475002 | 844 NH | 4 - 10" | 100 - 250 | 1.6 mm | 0.5 µm | 2 µm | 230 mm |
| 4475003 | 844 NH | 10 - 16" | 250 - 400 | 2.6 mm | 1.5 µm | 3 µm | 336 mm |
| 4475004 | 844 NH | 16 - 32" | 400 - 800 | 2.6 mm | 1.5 µm | 3 µm | 336 mm |
| 4475005 | 844 NH | 10 - 32" | 250 - 800 | 2.6 mm | 1.5 µm | 3 µm | 336 mm |
| Order no. | Product type | Measuring range inch | Measuring range mm | Repeatability fw (µm) | Error limit Ge (µm) |
|---|---|---|---|---|---|
| 4474179 | 844 NB | 0.79 - 2" | 20 - 50 | 1 µm | 4 µm |
| 4474180 | 844 NB | 2 - 4.33" | 50 - 110 | 1 µm | 3 µm |
| 4474186 | 844 NB | 4.33 - 11.81" | 110 - 300 | 1 µm | 2.5 µm |
